New section rollers for sale.
VersaRoll section rollers are high performance section rollers with great features. All of our section rollers are supplied with the accessories you need to roll flat bar, square bar, square tubing, round bar and many other bar profiles. We sell, service and guarantee our section rollers and larger engineering and fabrication machine tools in South Africa, Botswana, Namibia, Zimbabwe, Mozambique and Zambia. Looking for used section rollers? Click here.
Technical Specifications:
- Upper roll shaft: 60 mm Ø
- Bottom rollers shaft: 50 mm Ø
- Roll diameter: 180 mm Ø
- Working speed: 5 m/min
- Motor Power: 3 kW
- Dimensions: 1200 x 850 x 1200 mm
- Weight: 1000 kg
- Flat bar (flange): 60 x 10 @ 500 Ø / 20 x 5 @ 250 Ø
- Flat bar (easy way): 80 x 20 @ 500 Ø / 50 x 5 @ 250 Ø
- Square Bar: 32 x 32 @ 400 Ø / 12 x 12 @ 250 Ø
- Round bar: 35 @ 350 Ø / 10 @ 250 Ø
- Round Tubing: 60 x 2 @ 600 / 15 x 1,5 @ 200 Ø
- Rectangular Tubing: 50 x 25 x 3 @ 450 Ø / 20 x 15 x 2 @ 250 Ø
- Square tubing: 45 x 3 @ 600 Ø / 20 x 2 @ 300 Ø
- Angle Iron (Toe out): 60 x 60 x 6 @ 650 Ø / 30 x 30 x 4 @ 350 Ø
- Angle Iron (Toe in): 50 x 50 x 5 @ 550 Ø / 30 x 30 x 4 @ 350 Ø
Standard Accessories:
- Steel construction welded frame
- 3 rolls are powered
- Hardened and ground shafts are made of high tensile special steel
- Rolls are hardened and ground
- Horizontal and vertical working position
- Hardened standard rolls
- Mobile control panel
- 3 Axis mechanical lateral angle guide rolls
- Brake motor equipped for precision bending
- Digital read-outs (2 pcs)
Optional Equipment:
Pipe, tube and profile bending rolls
Hydraulic lateral guide rolls
Automation with NC and CNC control
Technical Specifications:
Steel welded construction frame
3 Rolls are motor driven
Hardened shafts from special steel material
Top roll hydraulic moveable up-Down
Horizontal and vertical working position
Standard rolls
Guide rolls
Brake motor equipped for the precision bending
Mobile control panel
Flat bar (flange): 60 x 10 @ 600 Ø / 20 x 10 @ 300 Ø (Standard rolls)
Flat bar (easy way): 100 x 15 @ 600 Ø / 50 x 10 @ 300 Ø (Standard rolls)
Square Bar: 35 x 35 @ 600 Ø / 15 x 15 @ 300 Ø (Standard rolls)
Round bar: 35 @ 600 Ø / 20 @ 300 Ø (Optional rolls)
Round Tubing: 70 x 2 @ 1200 Ø / 25 x 1.5 @ 400 Ø (Optional rolls)
Rectangular Tubing: 70 x 30 x 3 @ 1500 Ø / 30 x 15 x 2 @ 400 Ø (Optional rolls)
Square tubing: 50 x 3 @ 1600 Ø / 20 x 2 @ 400 Ø (Optional rolls)
Angle Iron (Toe out) 50 x 50 x 6 @ 600 Ø / 30 x 30 x 3 @ 400 Ø (Optional rolls)
Angle Iron (Toe in) 50 x 50 x 6 @ 900 Ø / 30 x 30 x 3 @ 600 Ø (Optional rolls)
Standard Accessories:
Steel construction welded frame
3 rolls are powered
Hardened and ground shafts are made of high tensile special steel
Rolls are hardened and ground
Horizontal and vertical working position
Hardened standard rolls
Mobile control panel
3 Axis mechanical lateral angle guide rolls
Brake motor equipped for precision bending
Optional Equipment:
Pipe / Tube Bending Rolls
Profile Bending Rolls
Angle Bending Rolls
Digital Read-Out
Optional lateral angle guides
Optional stairway bending attachment
NC control
More information on our New Sahinler PK35F Motorised Section Bender available for sale, is listed below:
Technical Specifications:
- Rolls Shaft: 50 mm Ø
- Roll Diameters: 155 mm Ø
- Working Speed: 4,5 m/min
- Motor Power: 1,5 kW
- Dimensions: 750 x 1000 x 1400 mm
- Weight: 400 Kg
- Flat bar (flange): 60 x 10 x 500 mm Ø / 40 x 10 x 400 mm Ø
- Flat bar (easy way): 100 x 15 x 450 mm Ø / 60 x 10 x 350 mm Ø
- Square Bar: 35 x 35 x 900 mm Ø / 20 x 20 x 300 mm Ø
- Round bar: 35 x 600 mm Ø / 30 x 400 mm Ø
- Round Tubing: 70 x 2 x 1000 mm Ø / 30 x 2 x 500 mm Ø
- Rectangular Tubing: 70 x 30 x 2 x 1200 mm Ø / 50 x 40 x 30 x 1200 mm Ø
- Square tubing: 50 x 3 x 1700 mm Ø / 40 x 3 x 600 mm Ø
- Angle Iron (Toe out) 50 x 50 x 5 x 800 mm Ø / 40 x 40 x 5 x 600 mm Ø
- Angle Iron (Toe in) 50 x 50 x 6 x 1000 mm Ø / 30 x 30 x 3 x 500 mm Ø
Standard Accessories:
- Steel Frame
- 2 Rolls directly driven by a gear system
- Rolls are hardened
- Rolls shafts are made of special steel material - hardened and ground
- Roll shafts housed by bearings
- Standard rolls
- Guide rolls
- Horizontal and vertical working position
Optional Equipment:
- Pipe / Tube Bending Rolls
- Profile Bending Rolls
- Angle Bending Rolls
- Digital Read-Out
- Special Lateral Angle Rolls
More information on our New Sahinler PK30F Motorised Section Bender available for sale, is listed below:
Technical Specifications:
- Rolls Shaft: 30 mm Ø
- Roll Diameters: 148 mm Ø
- Working Speed: 2-4 m/min
- Motor Power: 0,7 - 0,85 kW
- Dimensions: 600 x 800 x 1450 mm
- Weight: 220 Kg
- Flat bar (flange): 50 x 10 x 800 mm Ø / 20 x 6 x 300 mm Ø
- Flat bar (easy way): 80 x 15 x 700 mm Ø / 30 x 6 x 400 mm Ø
- Square Bar: 30 x 30 x 900 mm Ø / 10 x 10 x 200 mm Ø
- Round bar: 30 x 900 mm Ø / 10 x 200 mm Ø
- Round Tubing: 60 x 1,5 x 1000 mm Ø / 25 x 1,5 x 600 mm Ø
- Rectangular Tubing: 50 x 30 x 3 x 1200 mm Ø / 40 x 20 x 2 x 800 mm Ø
- Square tubing: 40 x 3 x 1200 mm Ø / 30 x 2 x 800 mm Ø
- Angle Iron (Toe out) 40 x 40 x 5 x 600 mm Ø / 30 x 30 x 4 x 300 mm Ø
- Angle Iron (Toe in) 35 x 35 x 5 x 600 mm Ø / 30 x 30 x 4 x 400 mm Ø
Standard Accessories:
- Steel Frame
- 2 Bottom rolls are powered
- Direct drive power system
- Top roll is idle (free turning)
- Hardened Rolls
- Roll shafts are made of special hardened and ground steel material
- Double speed motor
- Standard Rolls
- Adjustable guide rolls
- Horizontal and vertical working position
Optional Equipment:
- Pipe / Tube Bending Rolls
- Profile Bending Rolls
- Angle Bending Rolls
- Digital Read-Out
- Special Lateral Angle Rolls
More information on our New Sahinler HPK100 Hydraulic Section Bender available for sale, is listed below:
Technical Specifications
Upper roller shaft 100 mm Ø
Bottom rollers shaft 100 mm Ø
Roll diameter 315 mm Ø
Working speed 7 m/min
Motor power 7.5kW
Dimensions 2000 x 1450 x 1700mm
Weight 3650 kg
Flat Bar (flange): 100 x 20 @ 800 Ø / 30 x 10 @ 400 Ø (Standard rolls)
Flat Bar (easy way): 200 x 30 x 1200 Ø / 160 x 35 @ 800 Ø / 80 x 5 @ 500 Ø (Standard rolls)
Solid Square Bar: 60 x 60 @ 750 Ø / 15 x 15 @ 400 Ø (Standard rolls)
Standard Accessories
Steel construction frame
3 rolls are hydraulic powered by planetary gearbox
Hardened and ground shafts manufactured from high tensile special steel
Horizontal and vertical working position
Hardened rolls - standard
Mobile control panel
3 Axis mechanical hand lateral angle guide rolls
Brake motor equipped for precision bending
Digital read-outs (2 pcs)
New! VersaRoll section rollers for sale.
6 month guarantee
Bend multiple bar profiles
Bend different thicknesses and different radii
Compact structure
2.2kW motor speed
13 RPM spindle speed
What is a section roller?
A section roller is a machine tool designed to roll varying thicknesses of bar steel into circular shapes with varying radii. Section rolers can be used to roll flat bar, square bar, round bar and various other bar profiles. With a special set of roller wheels, section rolls can also be used to roll tubing into various radii. One of the most common uses for section rolls is to roll flanges that are used in various engieering and fabrication applications.
More information on our New Sahinler HPK 80 Hydraulic Section Bender available for sale, is listed below:
Technical Specifications:
Standard Accessories:
Optional Equipment:
